Project Description

MZ Series Herb Vibration Mill

Adopting German technology, high-precision machinery mill, continuous technological innovation and upgrading, suitable for 100-5000 mesh (150μm-2.5μm).

  • Product features:

    Easy to handle, clean, suitable for refueling operation, adjustable amplitude, various configurations such as normal temperature, water cooling, low temperature, ultra low temperature, anti-oxidation, anti-explosion, etc. to reduce the temperature in the grinding chamber, which is conducive to the grinding of heat sensitive materials, suitable for micron-sized grinding operation.

  • Applicable industries:

    Suitable for the grinding of toughness, fiber, sponge, high oil and high sugar content of materials which are difficult to be grinded by general grinders. Also for hardness and brittle materials. Widely used in Chinese herbal medicine, medicine, food, health products, cosmetics and other industries.

For more information, please Email or call our 24-hour hotline.

[email protected]     0086-532-66983518

For more information, please Email or call our 24-hour hotline.

[email protected]

0086-532-66983518

Inquiry
Download

Advantages | Working Principles | Atlas/Video | Technical Parameters | Cases | Applications & Services | Related Products | Get Quotation

Unique Advantages

To achieve ultrafine, high purification, functional, intelligent, carbon reduction, energy conservation and environmental protection is the mission and responsibility that time has given us.

Wide range of application

Suitable for dry, wet grinding, precision mixing, coating.

Fully enclosed, no pollution

Fully enclosed state during grinding process, no dust, no environmental pollution.

Very low operating costs

Easy to repair and the operating costs are very low.

PLC programming control

Using PLC programming control, achieve hierarchical authority management, storable, vibration sensors etc. using effective warning to prevent problems before they occur.

Working Principle

Creating the future of advanced materials with powder technology.

By strong vibration of the vibration source, the material in the grinding chamber is in the fluidized state, and is subjected to the high-strength impact of the grinding rod, such as collision, cutting, grinding and squeezing, so that the material can reach the micron pulverization or cell wall disruption in a short time. At same time, the grinder can also be used as a precision mixer and a coating modifier. By adjusting the intensity of vibration, it is convenient to control the fineness of the material to be grinded. Dry and wet pulverizing operations are both available. Meet GMP requirements, easy to assemble and disassemble, suitable for refueling operations. It has various working configurations such as normal temperature, water cooling, low temperature, ultra-low temperature, anti-oxidation and anti-explosion, which can reduce the temperature in the grinding chamber and facilitate the crushing of heat-sensitive materials. Widely used in Chinese herbal medicine, medicine, food, health products, cosmetics and other industries. It is a grinder with simple process and high cost performance.

Product Atlas

From dots to planes, from detail to the whole, from product to management, and from consultation to compliant production, we have always insisted on the relentless pursuit of perfection and the courage to surpass ourselves.
More product images / videos

Technical Parameters

Germany’s exquisite technology has been passed down and carried forward by us. Over 15 patents have enabled our products to lead the world.
Parameter MZ03 MZ06 MZ10 MZ30 MZ50 MZ100 MZ200
Chamber Volume 3L 6L 10L 30L 50L 100L 200L
Grinding Volume 0.6L 1.2L 2L 5L 10L 20L 40L
Voltage 220V Three-phase 380V Three-phase 380V Three-phase 380V Three-phase 380V Three-phase 380V Three-phase 380V
Power 0.37kw 1.1kw 0.75kw 1.5kw 2.2kw 3.7kw 7.5kw

Note: The production capacity is closely related to the particle size, specific gravity, hardness, moisture and other indicators of the raw materials. The above is only for selection reference.

Related Engineering Case

More than 1,000 stories have been collected here. the next one, told by you.
More Engineering Cases

Applications and Services

Equipment is the foundation, technology is the soul, and service is the guarantee.

Applicable material

This equipment is suitable for the grinding toughness, fiber, sponge, high oil content and high sugar content of materials which are difficult to be grinded by general grinders, also for grinding hardness and brittle materials. Widely used in ultra-fine grinding in Chinese herbal medicine, medicine, food, health care products, cosmetics and other industries.

Learn more

Customer Service

From your first call, to the next communication, inspection, testing, detection analysis, determining the product model and process flow, to complete equipment manufacturing, installation and commissioning, worker training and compliance production, we will ensure that every step is implemented in place. In order to make you a word-of-mouth communicator of ALPA products and services, we will spare no effort.

Learn more

Product Parts

The parts service provided by ALPA has been servicing more than 1,000 customers for 18 years and has been proven by markets. The parts are shipped quickly, with full stock, good quality, low loss and long service life, ensuring the continuous and stable operation of your equipment.

Learn more
